Fireshield® STEEL 1002
Waterbased 30 to120min FRR protection.
NZ Specifications
for STEEL 1002 - Single pack waterborne >120mins FRR
Steel 1002 Technical Datasheet
Steel 1002 Safety Datasheet
Fireshield Steel Systems Chart
Fireshield Steel 1002 Building Product Information Sheet
Product Fact Sheet
Fire Rated Historical Structural Timber
Green Star Products
Steel Attachments + Expansion Guide
Approved Primers
Approved Top Coats
Australia Specifications
for STEEL 1002 - Single pack waterborne >120mins FRR
Specifications will be loaded shortly
Substrate | Steel and Structural Timber
Fire Rating | 30 to 120 minute
Type | Waterborne
Environmental | Green Star + Declare / Red List Free
Fireshield® Steel 1002 is a more environmentally friendly waterborne intumescent coating for the protection of interior structural steel sections optimised for 30 to 120 minutes protection from cellulosic fires in C1-C2 interior environments.
Characteristics:
-
Thin film technology, quality finish.
-
Environmentally friendly Green Star, Declare and Red List Free.
-
Simple on-site application.
-
Low odour, low VOC.
Advantages:
-
Timber and plasterboard can be direct fixed to coated surface.
-
Can be used as part of the Korok 2-way fire wall design system.
-
Ideal for Green Building projects.
-
Low odour, low VOC.
-
Steel 1002 can also be used to fire rate existing timber in historic buildings such as floor joists, floorboards and structural beams and columns. Contact Fireshield for more information on this specific design solution.
At A Glance
Type |
Waterborne intumescent basecoat |
Fire Protection |
30 to 120 minutes FRR |
Volume Solids |
68% by volume |
VOC |
<50 grams/litre |
Environmental |
Zero Halogens +Red List & Declare |
Install Location |
Interior C1 - C3 |
Specifications:
Masterspec section 6742FS or contact Fireshield direct for assistance.
Compliance:
New Zealand:
Fire tested to EN13381-8:2013 and assessed by Exova Warringtonfire to BS476 parts 21 and 22 and 5th Edition Yellow Book using NZS 3404: Part 1, 1997 and complying with the New Zealand Building Code B1/VM1 and C2/AS1-C6/AS1 Section C5.1.1.
Australia:
Not available
Additional Information:
Steel 1001 is part of the Fireshield Cladding Study and has been tested with timber, Korok walls and plasterboard directly attached to the coated surface, contact Fireshield to apply the study to your next project.
